SV700 E-VAC IN LINE VACUUM PUMP

The SV E-Vac In Line Vacuum Pump is designed as an in line system allowing the conversion of a standard pipeline into a fixed vacuum system.

The SV E-Vac can be fitted to a range of pipes including HDPE, steel or even flexible suction hose which offers considerable flexibility.

Operating on a variable range of air supplies the SV E-Vac In Line Vacuum Pump can consistently deliver up to 25”Hg+ of vacuum enabling the capture and transfer of most materials.

The unit can be installed with various nozzles ranging from 100 cfm for viscous liquid transfer up to 280cfm at 85 psi to 100psi for solids recovery.

The SV E-vac must be installed on a 30deg angle or higher but becomes a virtual straight through system ideal for tank cleaning, ship hull installation or hard access sumps with variable contents.

SV700- SUPAVAC

Features

  • 100% air powered operation
  • Intrinsically safe
  • No internal workings
  • High vacuum and high airflow
  • Fully automatic operation
  • Can be fitted to any piping configuration
  • Robust construction
  • Ideal for use in confined spaces
  • Also available in Class 3 carbon, 316 stainless steel or polyurethane coated tanks

Applications

  • Conveyor boot end trouble spots
  • Sump cleaning
  • Confined space installations
  • Tank and pit cleaning
  • Hazardous waste recovery
  • Drilling mud transfer
  • Open sump installations
  • FPSO tank cleaning
SV700- SUPAVAC Application

Technical Data

  • Height 60 cm
  • Width 50 cm
  • Weight 145 kg
  • Air consumption 100-280CFM at 85psi to 100psi+
  • Up to 25”Hg+ (85kPa) vacuum
  • Suction inlet and Discharge outlet 75 mm (3”) 100 mm (4”)
  • Discharge outlet 100 mm (4”)
  • Handles solids to 50 mm (2”)
