SV30 - Portable Solids Pump

The SV30 Portable Solids Pump is a one person vacuum loading, pressure discharge pump capable of recovering and transferring almost any flowable sludge or slurry.

The SV30 Portable Solids Pump is 100% air powered and operated, generates up to 22″Hg+ of vacuum combined with high airflow which allows the unit to transfer materials typically considered un-pumpable.

For more than 25 years SupaVac solids pumps, slurry pumps and sludge pumps have been employed worldwide servicing oil & gas, drill rigs, marine tank cleaning, mining, municipal, industrial, agriculture, and construction industries.

The SV30 slurry pump or sludge pump has been specifically designed for the market where a smaller, more portable solution is required.  Think tank cleaning or similar applications and you’ll get an idea of where the SV30 truely excels.

SV30 also comes as standard with Next Generation pneumatic controls which allow for better control and energy power savings.

SV30 - SUPAVAC

Features

  • Multipurpose vacuum pump
  • Portable and compact
  • Lightweight robust constructions
  • 100% compressed air operation
  • Intrinsically safe
  • Fully automatic
  • Versatile
  • No internal moving components
  • Minimal maintenance
  • Recovers material from up to 30 metres (98ft)
  • Delivers up to 300 metres (984ft)

Applications

  • Waste management solids control
  • Effluent transfer
  • Drilling mud waste
  • Agricultural product and waste transfer
  • Food and beverage
  • Corrosive slurries
  • Spillage recovery and transfer
  • Sump cleaning and desilting
  • Tank sludge extraction
  • Municipal waste
  • Garnet sludge
SV30 SUPAVAC SOLIDS PUMP

Technical Data

  • Height 55 cm (22″)
  • Width 45 cm (18″)
  • Length 129 cm (51″)
  • Weight 66 kg (146lb)
  • Throughput capacity up to 14m3/hr (61USGPM) @ SG1.0
  • Air consumption option 80cfm at 102psi (38 L/sec at 7 bar)
  • 125cfm at 102 psi (59 L/sec at 7 bar)
  • Air supply connection 25mm (1″)
  • Up to 22″Hg (75kPa) vacuum at 102psi (7 bar)
  • Suction 50 mm (2″) BSP/Type B camlock
  • Discharge 50 mm (2″) BSP/Type A camlock
  • Handles solids to 35 mm (1.3″)
  • Carbon steel vessel

What is SupaVac?

SupaVac is the global market leader in air operated ultra tough vacuum pumping units capable of transferring any flowable material across a wide range of mining, oil & gas, FPSO & tanker tank cleaning, agricultural, industrial and municipal applications. Pumping the un-pumpable!

The SupaVac range of Slurry Management Systems and vacuum pumps offers an efficient and economical solution to most pumping challenges.

Abouttitle_logo_2

Since 1993 the patented SupaVac product range has been designed & manufactured in Australia and demanded globally across a wide range of industries with proven performance in the most challenging applications.

The SupaVac patented product range is owned and manufactured by precision engineering company Poche Engineering, with 80+years of manufacturing experience and part of the larger engineering group, Fluid Power Engineering Solutions Pty Ltd.

Global Distribution & Support

With 25 years experience SupaVac is the Industry Leader & Globally recognised Solution for transferring difficult to pump materials. SupaVac has been distributed to all corners of the globe, as the vacuum pump of choice in handling tough pumping applications.

Over the years SupaVac has proven continued credibility in performance and quality, therefore developed strong relationships with partners across the globe to service & support customers locally.

Need help with a challenging pumping application?

Get in touch with our experienced SupaVac team who can help guide you through the SupaVac product range to select the most efficient & cost effective product for your pumping application.
